Tiger-1800B
5.0
Brands   :
Category   :เครื่องพิมพ์ Sublimation
Textile Printer "Pro series"
Belt-Type Direct-to-Textile Inkjet Printer High-Speed Range Model "Tiger-1800B"
Maximum print speed: 385 m2/h
Ask for Infomation
Compare
Interested
Request Quotation


Exceptional print speed
Tiger-1800B features 16 printheads arranged in two staggered lines (each line has 8 printheads). It achieves maximum print speeds of up to 385 m2/h (*) in high-speed mode.
* High speed (3 drop size) mode (600 × 600 dpi, 1 pass, Bi) Textile width: 1,850 mm

Configuration of printhead



Print speed (Tiger-1800B)


Plotting Method
1 pass mode: High speed printing is possible
In 1 pass mode all printheads are used. One print width is equivalent to two staggers, and printing at high speed is possible.



1 pass mode: High speed printing is possible
1 pass, 2 layers mode: High density printing is possible
In 1 pass, 2 layers mode, rear row stagger of the headprint is used and printing is at the same density as in 1 pass mode. Front row of the headprint prints overlapping on the same place.
It is a 1 pass mode density x 2, which makes possible a high density printing results.



Droplet print mode selection suitable for print data
Depending on ink type and printing mode, there are 4 different droplet sizes. Droplet print mode can be choose to match the print data from high speed and standard mode.

1) High speed (3 droplet size) mode
Ideal for fine design data such as thin lines and for light colors printing.

* Droplet size for reactive dye ink (MLRc500)


2) Standard (4 droplet size) mode
Ideal for printing where density is required such as monochromatic colors.

* Droplet size for reactive dye ink (MLRc500)


Stable and reliable mechanism secures high-speed printing
  1) Stable textile transportation mechanism
Textile transport security is achieved by the twin pressure roller shafts attached to the edge of the transportation belt. Textiles are uniformly applied without wrinkling onto the belt through the upper and lower rollers (Fig. 1), assuring stable textile transportation. Furthermore, the wrinkle and jam sensors detect textile wrinkling or creasing early in order to minimize potential damage to the printheads from collisions with raised or jammed textiles.

  2) Degassing module and ink circulation mechanism maintain optimum ink conditions
Air bubbles generated in the ink can lead to missing nozzles because such bubbles act as cushions that decrease ink ejection power. To assure stable ink-jetting, each model of the Pro　series has a degassing module that removes bubbles and constantly circulates ink.

  3) Automatic wiper cleaning
Cleaning liquid is automatically applied to each wiper before and after head cleaning. This liquid enhances the cleaning effect during the head-cleaning process, ensuring a clean wiper and reducing daily maintenance time. Furthermore, as each printhead has its own wiper, quick and effective cleaning is enabled while color mixing in the printheads is avoided.

Extensive optional units for accommodating various applications
Various optional units are offered to fit a range of production needs

1) Feeding units
  • Rolled textile feeding unit - This unit is used for feeding rolled textiles and is equipped with a centering system and tension bars.
  • Jumbo roll feeding unit - This unit is used for feeding large-sized, long-rolled media.

2) Drying and Take-up units
Large heating unit + Folding arm unit for Tiger-1800B
  • Large heating unit
This unit can dry special and high density printed fabric. It is effective also for wool and the like which is difficult to dry.
* The standard size heating unit that comes with "Tiger" main unit is not needed when purchasing a large heating unit.
  • Folding arm unit
This unit folds and stores printed textiles. It can be used with both standard and large heating units.

Product outline of Textile Printer "Pro series"
The Pro Series, with its outstanding stability and high-precision printing technology, is a high-speed range model dedicated to speed and beautiful printing.

Exceptional print speed
Tiger-1800B features 16 printheads arranged in two staggered lines.

Droplet print mode selection suitable for print data
Depending on ink type and printing mode, there are 4 different droplet sizes. Droplet print mode can be choose to match the print data from high speed and standard mode.

Stable and reliable mechanism secures high-speed printing
  • Textile is uniformly applied onto the transportation belt by twin pressure roller shafts attached to the edge of the belt. Additionally, the wrinkle and jam sensors minimize the damage to the printhead through early detection of wrinkles and jams.
  • The degassing module eliminates air bubbles in the ink to prevent missing nozzles and deliver stable ink-jetting.
  • Each printhead is automatically cleaned by a dedicated wiper. This function saves the maintenance time and improves the print quality by avoiding color mixing in the printheads.

Extensive optional units for accommodating various applications
To meet diverse material and production needs, The Pro series provides various optional units:
  • Feeding units for jumbo rolls or folded fabrics
  • Heating units
  • Folding arm unit for storing fabric in the box after printing

Large-sized ink tank (10 kg) ensures cost-effective print operation.
The bulk ink supply enables effective long-hour printing while reducing the operational cost.

High-performance software RIP "TxLink3 Standard"
The TxLink3 Standard offers simple RGB and CMYK color replacement on raster and vector data, as well as the ability to produce different color patterns. Moreover, various color replacement functions can represent desired colors.
Information
Printhead
16 Staggered arrangement (Each line has 8 printheads)
Print resolutions
600dpi
Maximum print width
1,850 mm (72.8 in)
Maximum media width
1,900 mm (74.8 in)
Roll core diameter
2 inch
Roll outer diameter
400 mm (15.75 in) or less
Roll weight
100 kg (220.5 lb) or less
*standard feeding, drying and take-up unit
Power supply
Main unit: 3 phase 380 V ± 10%, 50 / 60 Hz 50 A or less
Heater: 3 phase 380 V ± 10%, 50 / 60 Hz 30 A or less
Operational environment
Temperature: 20 °C – 25 °C (68 °F – 77 °F)
Humidity: 35% – 65% Rh (Non condensing)
Power consumption
Printer : 22 kW
Drying and take-up unit : 14 kW
Dimensions (W × D × H)
Main unit: 5,250 mm × 2,700 mm × 2,000 mm
(206.7 in × 106.3 in × 78.7 in)
Drying and take-up unit: 2,825 mm × 1,300 mm × 980 mm
(111.2 in × 51.2 in × 38.6 in)
Weight
Main unit: 4,800 kg (10,582.2 lb)
Drying and take-up unit: 1,200 kg (2,645.5 lb)
Software
Software
High-performance software RIP "TxLink3 Standard" is bundled.
Ink Type / Color
Reactive dye ink: MLRc500 (C, M, Y, K, Or, Bl, R, Lk)
Acid dye ink: TBD
Sublimation dye ink: TBD
Textile pigment ink: TBD
Packaging Ink
10 kg (22 lb) tank
Loadable ink color
8-color
Certifications
CE Marking (EMC, Machinery directive, and RoHS)
Interface
USB 2.0 / Ethernet
